Model 75Q691F
TCL 75" Q Class 4K UHD HDR QLED Smart TV with Fire TV – 75Q691F
- 4K UltraHD Resolution
- QLED PRO – Quantum Dot Technology
- Full Array Local Dimming
- High Brightness PRO LED Backlight
- HDR PRO+ with Dolby Vision, HDR10+, HDR10, & HLG
- Motion Rate 240 with MEMC Frame Insertion
- Game Accelerator 120
- Auto Game Mode (ALLM)
- Dolby Atmos Audio
- Onkyo 2.1 Speaker System
- Enhanced Dialogue Mode
- DTS Virtual:X
- Bluetooth Personal Audio
- FullView 360 Metal Bezel-less Design with Width Adjustable Feet
- 4 HDMI Inputs including one with eARC
- Wi-Fi 5
- Apple Airplay 2
- Works with Amazon Alexa
Suggested Price
$1,199.99
SCREEN SIZE
- Overview
- Specifications
- Downloads
- Reviews
4K Ultra HD Resolution
Experience incredible detail with 4X the resolution of 1080p Full HDTVs.
QLED PRO
Rich, vibrant colors covering nearly the entire DCI-P3 color space to bring images to life.
Full Array Local Dimming
Local dimming that dynamically adapts to on-screen content for deep blacks and great contrast.
HDR PRO+
Enjoy enhanced contrast, accurate colors and fine details utilizing all the most advanced HDR formats.
High Brightness PRO LED Backlight
With up to 600 Nits peak brightness, Q691F models create bright images with dazzling specular highlights, for a truly immersive and realistic cinematic experience.
Motion Rate 240 with MEMC Frame Insertion
Combines multiple motion enhancement technologies for best-in-class motion clarity.
QLED PRO - Quantum Dot Technology
Rich, vibrant colors covering nearly the entire DCI-P3 color space to bring images to life.
Full Array Local Dimming
Local dimming that dynamically adapts to on-screen content for deep blacks and great contrast.
High Brightness PRO LED Backlight
With up to 600 Nits peak brightness, Q691F models create bright images with dazzling specular highlights, for a truly immersive and realistic cinematic experience.
HDR PRO+ with Dolby Vision, HDR10+, HDR10, & HLG
Enjoy enhanced contrast, accurate colors and fine details utilizing all the most advanced HDR formats.
Motion Rate 240 with MEMC Frame Insertion
Combines multiple motion enhancement technologies for best-in-class motion clarity.
Game Accelerator 120
With up to fast 120Hz VRR, enjoy more responsive gameplay without lag, designed to keep you at the top of any leaderboard.
Auto Game Mode (ALLM)
Automatically enables game mode for the lowest possible input lag and latency for an unmatched gaming performance.
Dolby Atmos Audio
Advanced spatial audio processing can be found in movies, TV shows, and video games.
Onkyo 2.1 Speaker System
High performance speakers specially tuned by Onkyo, a legendary Hi-Fi audio company.
DTS Virtual:X
Advanced audio post-processing for your everyday content offering an immersive 3D sound, all from just your TV speakers.
FullView 360 Metal Bezel-less Design with Width Adjustable Feet
Elegant edge-to-edge glass design, sleek back panel, and height adjustable feet to allow for greater versatility when choosing TV furniture or a Soundbar.
| TCL Q Class - Q691F | |
|---|---|
|
Model Model No Tooltip
|
75Q691F |
|
Screen Size Screen Size No Tooltip
|
75" |
|
Viewable Display Size Viewable Display Size No Tooltip
|
74.5" |
|
Description Description No Tooltip
|
An Easy Choice for QLED |
|
Wi-Fi Wi-Fi No Tooltip
|
Wi-Fi 5 (802.11ac) |
| Features | |
|---|---|
|
Control Buttons Control Buttons No Tooltip
|
One Button |
|
Multilingual On-Screen-Display Multilingual On-Screen-Display No Tooltip
|
Yes |
|
Closed Caption Closed Caption No Tooltip
|
Yes |
|
Parental Control (V-Chip) Parental Control (V-Chip) No Tooltip
|
Yes |
|
Accessible Menu System (CVAA) Accessible Menu System (CVAA) No Tooltip
|
Yes |
|
Sleep Timer Sleep Timer No Tooltip
|
Yes |
|
JPEG / MP3 for USB JPEG / MP3 for USB No Tooltip
|
Yes |
| Audio | |
|---|---|
|
Audio Power (Watts) Audio Power (Watts) No Tooltip
|
50W - 2*15W + 20W |
|
Audio Passthrough Audio Passthrough No Tooltip
|
Dolby Atmos, Dolby Digital +, Dolby Digital, PCM |
|
Dolby Processing Dolby Processing No Tooltip
|
Dolby Atmos, Dolby Digital + |
| Smart Platform | Signal Format Compatibility |
|---|---|
|
Fire TV Fire TV No Tooltip
|
ATSC, NTSC, Clear QAM |
| Display | |
|---|---|
|
Display Technology Display Technology No Tooltip
|
QLED |
|
Panel Refresh Rate Panel Refresh Rate No Tooltip
|
60Hz |
|
Panel Resolution Panel Resolution No Tooltip
|
4K Ultra HD (3840 x 2160) |
|
Display Colors Display Colors No Tooltip
|
1.07 billion |
|
High Dynamic Range Format High Dynamic Range Format No Tooltip
|
HDR PRO+ (Dolby Vision, HDR10+, HDR10, HLG) |
|
Motion Enhancement Technology Motion Enhancement Technology No Tooltip
|
Motion Rate 240 with MEMC Frame Insertion |
| Connections - Inputs/Outputs | |
|---|---|
|
AV Input AV Input No Tooltip
|
Composite Video + L&R Audio In (Mini 3.5mm connector) |
|
Audio Output Audio Output No Tooltip
|
1 |
|
RF Input (NTSC, ATSC) RF Input (NTSC, ATSC) No Tooltip
|
1 |
|
Ethernet Ethernet No Tooltip
|
1 |
|
USB USB No Tooltip
|
2 x USB 2.0 |
|
HDMI HDMI No Tooltip
|
4 HDMI (1 eARC) |
|
SPDIF Digital Audio Optical SPDIF Digital Audio Optical No Tooltip
|
1 |
|
Audio Output Headphone Audio Output Headphone No Tooltip
|
1 |
| Product & Package Information | |
|---|---|
|
Product Size (WxHxD) with Stand Product Size (WxHxD) with Stand No Tooltip
|
65.80" x 40.60" x 14.60" |
|
Product Size (WxHxD) without stand Product Size (WxHxD) without stand No Tooltip
|
65.80" x 37.90" x 2.8" |
|
Stand Separation Distance Stand Separation Distance No Tooltip
|
57” |
|
Product Weight with stand (lbs) Product Weight with stand (lbs) No Tooltip
|
60.63 lbs |
|
Product Weight without stand (lbs) Product Weight without stand (lbs) No Tooltip
|
59.30 lbs |
|
Package Size (WxHxD) (inches) Package Size (WxHxD) (inches) No Tooltip
|
72.83" x 44.29" x 7.48" |
|
Total Package Weight (lbs) Total Package Weight (lbs) No Tooltip
|
84.44 lbs |
| VESA Mounting Specifications | |
|---|---|
|
VESA Hole Pattern VESA Hole Pattern No Tooltip
|
400 x 400 |
|
Screw Size Screw Size No Tooltip
|
M6 x 40 |
| Base Stand Specifications | |
|---|---|
|
Screw Size (Qty) Screw Size (Qty) No Tooltip
|
M5 x 4 |
| Energy Information | |
|---|---|
|
Energy Star Energy Star No Tooltip
|
No |
|
Standby Power Standby Power No Tooltip
|
＜0.5W |
| Accessories (Included) | |
|---|---|
|
Warranty Info / Quick Start Guide (QSG) Warranty Info / Quick Start Guide (QSG) No Tooltip
|
1/1 English |
|
Remote Control Remote Control No Tooltip
|
Voice Remote |
|
Remote Control Battery Remote Control Battery No Tooltip
|
Two "AAA" |
| Warranty |
|---|
|
3 year limited warranty 3 year limited warranty No Tooltip
|
