Model 65R648

TCL 65" Class 6-Series 8K Mini-LED QLED Dolby Vision HDR Smart Roku TV - 65R648

  • Brilliant 8K HDR picture quality
  • Mini-LED backlight display technology
  • Wide Color powered by QLED technology
  • HDR Pro Pack featuring Dolby Vision high-dynamic range (HDR)
  • Contrast Control Zone technology maximizes contrast
  • AiPQ Engine™ technology intelligently enhances picture as you watch
  • Stream free TV, live news, sports, movies, and more
  • Variable Refresh Rate (VRR) provides seamless gameplay
  • Auto Game Mode for an optimized fast-response gaming experience
  • Easy Voice Control works with Siri, Alexa, and Hey Google
  • Share videos, photos, and music from your Apple device using AirPlay
  • Simple, customizable home screen
  • FullView edge-to-edge glass design
  • Integrated cable management makes your TV setup clean and clutter-free
  • Cord cutting made easy with digital TV tuner and smart features built in
  • Advanced Digital TV Tuner with Live TV Channel Guide
  • Voice remote with shortcuts to popular channels
  • Dual-band WiFi & Ethernet port
  • 4 HDMI inputs (1 eARC)

Suggested Price
$2,199.99

Welcome to the Future of TV

An incredible 33 million pixels and astonishing clarity is infused into what's already a powerful performer.

QLED

QUANTUM DOT TECHNOLOGY

Experience vivid wide color and striking contrast, matching the format of Hollywood content creators.

Local dimming

CONTRAST CONTROL ZONES™ WITH MINI-LED BACKLIGHT TECHNOLOGY

Contrast is optimized across localized zones for striking differences between bright and dark areas of the image.

Game studio Pro

GAME STUDIO PRO™

Arsenal of features let you enjoy the smoothest action and an optimized fast-response gaming experience.

Dolby Vision Dolby Atmos

DOLBY VISION® & DOLBY ATMOS®

Dolby Vision delivers superior color and contrast while Dolby Atmos provides immersive surround sound.

8K Picture Resolution

8K PICTURE RESOLUTION

With four times the clarity of 4K, experience an incredibly lifelike picture.

AiPQ

AiPQ ENGINE™

TCL's AiPQ Engine optimizes color, contrast, and stunning clarity for an unrivaled 8K HDR experience.





Smart 8K

Pixel Perfection

8K display resolution certified by the 8K Association features over 33 million powerful pixels with four times the clarity and sharpness of 4K TVs.

TCL 8K TV
TCL 8K TV
Ai 8K TV
AiPQ

A Smart Picture that Adjusts as you watch

TCL's AiPQ Engine™ technology is driven by machine-learning to intelligently enhance color, contrast, and clarity, as you watch for an unrivaled 8K HDR experience with vibrant color, sharp clarity, and dramatic depth.

Smart HDR

Smart HDR

With TCL’s exclusive Smart HDR technology, every video frame is carefully monitored and referenced to an AI-curated library of high-quality video content to ensure delivery of maximum color accuracy and dynamic impact.



Smart 8K Upscaling

Smart 8K Upscaling

With TCL’s Smart 8K Upscaling technology, improved clarity and sharpness of lower-resolution video is optimized using a unique machine-learning process that corrects the errors commonly introduced in less advanced 2-dimensional resolution enhancement technologies.

Smart Contrast

Smart Contrast

With Smart Contrast technology, the Contrast Control Zone performance of TCL TVs are optimized to enhance the dramatic transitions between the brightest whites and darkest blacks, while still minimizing unwanted halo or banding effects.

8K Mini-LED TV
Mini-LED

High-performance Display

TCL's Mini-LED technology delivers precise contrast control and incredible brightness, for dramatic highlights and lifelike HDR performance.

QLED
QLED

Over a Billion Brilliant Colors

Quantum dot technology lets you experience lifelike picture quality with vivid wide color and striking contrast.

Dolby Vision HDR
HDR

Immerse Yourself in Every Detail

Experience breathtaking realism with Dolby Vision, the premium high-dynamic range experience.

CONTRAST, CONTROLLED.

Contrast is individually optimized across the image with up to 240 zones for striking contrast between bright and dark areas.

Contrast Control Zones
Contrast Control Zones
Next-gen 4K 120Hz gaming
Game Studio Pro™

Play like a pro

TCL has a full arsenal of features that optimize big-screen gaming performance, so you have a competitive edge. Game Studio ensures cinema-quality graphics, powerful audio, smooth play, and near-instant responses—everything you need for immersive, next-level gaming.

Auto Game Mode ALLM

Auto Game Mode (ALLM)

Game mode will be engaged automatically for the smoothest action, lowest latency and the best picture settings for gaming.¹

Variable Refresh Rate VRR

Variable Refresh Rate (VRR)

Dynamic refresh rate adjusts to your content to produce smoother, seamless gameplay as video game creators intended.

6-Series
8K Streaming

Unbox the Unimaginable

Explore Earth's diversity and wonders in razor-sharp 8K resolution on the award-winning channel, The Explorers. For a limited time, new 6-Series 8K users get 3 months of Explorers+, so you can immediately dive into 8K and be amazed.⁶

Your favorites. Your way.

Endless Entertainment with Roku TV built-in

Entertainment at your Fingertips

With America's #1 streaming platform² built-in, you'll enjoy an easy, lightning-fast experience and automatic updates with the newest channels and features so your TV gets even better over time.³

Cable, streaming, cord cutter friendly

Choose How You Watch

Watch your favorite entertainment however you choose, whether it’s through a streaming service, cable or satellite subscription or free over-the-air channels. The possibilities are endless.

You call the shots.

Mobile App Control

Powerful Control in your Hands

Use the free Roku mobile app for iOS® and Android as a second remote, or to access fun and convenient features like voice search and control, private listening, and even use your mobile keyboard for faster typing.⁴

Easy voice control works with Siri, Alexa, Hey Google

Let Your Voice Be Heard

Ask Alexa or Hey Google to launch channels, search for entertainment, control your streaming, and more. You can also control your TV using the Apple Home app or Siri on your Apple devices.⁵ Or, control your streaming with the included Voice Remote.

¹ Compatible game console required.

² Source: Kantar, based on streaming hours, May 2020

³ Payment required for some channels and content. Channels can change and vary by region.

⁴ Limitations apply to the mobile app. See support.roku.com for device compatibility information.

⁵ Google is a trademark of Google LLC. Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. AirPlay, HomeKit, and Siri are trademarks of Apple, Inc. AirPlay and HomeKit are compatible with select 4K Roku devices. Third party voice assistant features and services may be subject to change or removal without notice.

⁶ The Explorers 8K premium subscription service – normally priced at $2.99/month, with 10% of revenues donated to The Explorers Foundation to protect biodiversity – is available through an exclusive limited-time offer to owners of 8K Roku TV models at no cost for the first three months. Visit theexplorers.com/tcl-8k to sign up and learn more.

TCL Series - R648

Model

Model

No Tooltip

65R648

Screen Size

Screen Size

No Tooltip

65"

Viewable Display Size

Viewable Display Size

No Tooltip

64.5"

Description

Description

No Tooltip

Powerful Performance Mini-LED QLED HDR 8K TV

WiFi

WiFi

No Tooltip

802.11ac 2x2 Dual Band (support 2.4GHz & 5GHz)

Features

Advanced PQ Setting with Mobile App

Advanced PQ Setting with Mobile App

No Tooltip

Yes

Control Buttons

Control Buttons

No Tooltip

One button

Multilingual On-Screen-Display

Multilingual On-Screen-Display

No Tooltip

English, Spanish, French, German, Portuguese

Closed Caption

Closed Caption

No Tooltip

Yes

Parental Control (V-Chip)

Parental Control (V-Chip)

No Tooltip

Yes

Accessible Menu System (CVAA)

Accessible Menu System (CVAA)

No Tooltip

Yes

Sleep Timer

Sleep Timer

No Tooltip

Yes

Easy Voice Control

Easy Voice Control

No Tooltip

Works with Siri, Alexa, and Hey Google

Live TV Pause from antenna (up to 30 minutes)

Live TV Pause from antenna (up to 30 minutes)

No Tooltip

Yes

Audio

Audio Power (Watts)

Audio Power (Watts)

No Tooltip

15W x 2 Speakers + 30W Subwoofer

Audio Passthrough

Audio Passthrough

No Tooltip

Dolby Atmos / Dolby Digital Plus / Dolby Digital / PCM

Dolby Processing

Dolby Processing

No Tooltip

Dolby Atmos / Dolby Digital Plus

Smart Platform Signal Format Compatibility

Roku

Roku

ATSC / NTSC / Clear QAM

Display

Natural Motion

Natural Motion

No Tooltip

Natural Motion 480

Panel Resolution

Panel Resolution

No Tooltip

7680 x 4320

Resolution

Resolution

No Tooltip

8K

Display Colors

Display Colors

No Tooltip

1.07 billion

High Dynamic Range Format

High Dynamic Range Format

No Tooltip

Dolby Vision, HDR10, HLG

Variable Refresh Rate (VRR)

Variable Refresh Rate (VRR)

No Tooltip

Yes

Auto Game Mode

Auto Game Mode

No Tooltip

Yes

Connections - Inputs/Outputs

AV Input

AV Input

No Tooltip

No

Audio Output (RCA)

Audio Output (RCA)

No Tooltip

No

RF Input (NTSC, ATSC)

RF Input (NTSC, ATSC)

No Tooltip

1

Ethernet

Ethernet

No Tooltip

1

USB

USB

No Tooltip

1 USB 2.0

HDMI

HDMI

No Tooltip

4 HDMI (Two HDMI 2.1 standard, plus one with eARC)

SPDIF Digital Audio Optical

SPDIF Digital Audio Optical

No Tooltip

1

Audio Output Headphone

Audio Output Headphone

No Tooltip

1

Product & Package Information 65"

Product Size (WxHxD) with Stand

Product Size (WxHxD) with Stand

No Tooltip

57" x 35.1" x 12"

Product Size (WxHxD) without stand

Product Size (WxHxD) without stand

No Tooltip

57" x 32.7" x 3.0"

Stand Width

Stand Width

No Tooltip

18.9"

Stand Depth

Stand Depth

No Tooltip

12.3"

Product Weight with stand (lbs)

Product Weight with stand (lbs)

No Tooltip

72.8 lbs

Product Weight without stand (lbs)

Product Weight without stand (lbs)

No Tooltip

70.1 lbs

Package Size (WxHxD) (inches)

Package Size (WxHxD) (inches)

No Tooltip

64.8" x 42.9" x 9.0"

Total Package Weight (lbs)

Total Package Weight (lbs)

No Tooltip

93.5 lbs

VESA Mounting Specifications

VESA Hole Pattern

VESA Hole Pattern

No Tooltip

400mm x 400mm

Screw Size

Screw Size

No Tooltip

M6 x 20

Base Stand Specifications

Screw Size (Qty)

Screw Size (Qty)

M5 x 20 (4)

Energy Information

Energy Star

Energy Star

No

Standby Power

Standby Power

<0.5W

Accessories (Included)

Warranty Info / Quick Start Guide (QSG)

Warranty Info / Quick Start Guide (QSG)

No Tooltip

1/1 English

Power Cord Type

Power Cord Type

No Tooltip

Detachable

Remote Control

Remote Control

No Tooltip

Pro Voice Enabled Remote Control RC580

Remote Control Battery

Remote Control Battery

No Tooltip

Two "AAA"

Warranty

1 year limited warranty

1 year limited warranty
